UniFlow MLX AireStream Fume Hoods
UniFlow MLX AireStream Fume Hoods are designed to accommodate larger equipment and laboratory procedures that traditional fume hoods cannot support.
Available in widths from 60” to 120” and depths from 30” to 48”, MLX fume hoods provide flexible configurations for demanding applications. These models are available in both constant air volume (CAV) and variable air volume (VAV) systems and feature modular construction for ease of installation and transport.
MLX fume hoods are designed for applications requiring larger workspaces and expanded interior capacity. Modular construction allows the unit to be disassembled for easier transport and installation.
Non-metallic construction provides total chemical and corrosion resistance for superior durability and long life. The modular fume chamber allows flexibility in installation and configuration.
Engineered airflow system with Vector airflow slots and transition bell exhaust connection ensures consistent airflow and improved containment performance.
Removable access panel allows convenient access to ducting, plumbing, and electrical services from a single connection point. Includes factory-installed vapor-proof LED lighting and controls.
30” vertical sash opening allows efficient loading and unloading of equipment. Features counterbalanced tempered safety glass and smooth operation.
43” viewing height provides unobstructed access and visibility within the fume chamber, allowing for large apparatus and complex setups.
Aerodynamic face opening improves airflow efficiency and directs air evenly into the chamber and through the baffle system.
Continuously monitors face velocity airflow to meet ANSI and OSHA requirements. Available in analog or digital configurations.
Sash stop located at the half-open position reduces airflow by up to 50% for improved energy efficiency.
Widths: 60”, 72”, 96”, 120”
Depths: 30”, 36”, 48”
CAV (Constant Air Volume) models
Optional VAV configurations
Optional explosion-proof lighting
Optional international electrical configurations
Optional sash configurations
Sash Options
Horizontal Sliding Sashes
Maximum opening is 50% Multi-panel design allows easy removal for cleaning and equipment setup.
Combination Vertical & Horizontal Sash
Provides both vertical access and horizontal efficiency. Allows full access to the fume chamber while maintaining energy savings.
UniFlow MLX AirStream Specifications & Ordering Info | (A) Width |
| 60" | 72" | 96" | 120" |
1. UniFlow MLX AireStream CAV Fume Hood: Air By-pass low flow, constant air volume hood. Dual wall modular construction, all non-metallic corrosion and fire resistant composite fiberglass construction. AireStream VaraFlow baffle system with vector slots and transition bell exhaust connection. Fume chamber has glass-smooth surface. Vertical sash to be counter balanced 3/16” tempered safety glass with chemical resistant non-metallic PVC framing track and aerodynamic sash lift. A sash stop is installed at the 1/2 open position. Vapor proof LED light fixture and control switch are wired to a single point junction box. 115V/60Hz, AC All electrical components are U.L. listed. Optional electrical services. | (B) Depth |
| ||||
| 65521 | 65621 | 65821 | 651021 | ||
30" | ||||||
36" | 65531 | 65631 | 65831 | 651031 | ||
48" | 65541 | 65641 | 65841 | 651041 | ||
2.UniFlow MLX AireStream VAV Fume Hood: Same as #1 above except equipped with variable air volume VAV restricted by- pass feature in place of CAV by-pass feature. Ducting must be connected to optional VAV exhaust system controls. | 30" | 65522 | 65622 | 65822 | 651022 | |
36" | 65532 | 65632 | 65832 | 651032 | ||
48" | 65542 | 65642 | 65842 | 651042 | ||
3. UniFlow MLX AireStream Fume Hood with Explosion Proof Light:Same as #1 above except, equipped with explosion proof vapor proof light fixture. Class I Division II Group A B C & D,Class II Division II Group F & G, 115V/60Hz U.L. listed fixture is installed but not wired. Must be field wired to comply with codes. | 30" | 65523 | 65623 | 65823 | 651023 | |
36" | 65533 | 65633 | 65833 | 651033 | ||
48" | 65543 | 65643 | 65843 | 651043 | ||
4. UniFlow MLX AireStream Fume Hood:Same as #1 above except equipped to comply to international electrical configuration. 220V/50Hz AC Optional international electrical configuration, electrical switches, receptacles available. | 30" | 65524 | 65624 | 65824 | 651024 | |
36" | 65534 | 65634 | 65834 | 651034 | ||
48" | 65544 | 65644 | 65844 | 651044 | ||
5. Horizontal Sliding Sash Option: Add suffix to number above |
| 65HS-5 | 65HS-6 | 65HS-8 | 65HS-10 | |
6. Combination Sliding Sash Option: Add suffix to number above |
| 65CS-5 | 65CS-6 | 65CS-8 |
| |
